On top of that, we include a Circuit Breaker Size Calculator further on (just insert watts and volts, and you get the correct breaker size).Īt the end, we also included the ‘just tell me the breaker size I need’ Breaker Size Chart that tells you what breaker size you need for devices with different wattages (from 50W units to big 20,000W devices).
50 amp breaker how to#
To help everybody sizing these breakers out, we will explain how to determine the right size of a breaker. If you know how to calculate the amps and account for the 80% breaker rule, you can calculate the size of the breaker yourself. You can calculate the amp draw from wattage and voltage.
Namely, if you run a 3,000W unit on a 220V circuit, the current is calculated like this: 3,000W / 220V = 13.63 amps. You will have to know how to convert 3,000W to amps. Sizing circuit breakers is all about amps. You usually have devices with known wattage let’s say a 3,000-watt air conditioner. Knowing how to calculate amps from wattage.You can read the full Article 240.4(B) in NEC 2014 on this here. This is a safety measure you better have a bit of overhead to prevent the circuit from frying. the specified ampacity of the circuit breaker. Example: If you have a 20 amp breaker, you can only allow for 16A current.
This is the most basic NEC (National Electric Code) rule that states that you can’t push the current over 80% of its specified ampacity.
Sizing a circuit breaker is actually quite easy. How do you go about picking the correct circuit breaker size? Do you need a 10A, 15A, 20A, 30A, 40A, 50A breaker, etc? Inadequately sizing a circuit breaker can lead to a fire. If we undersize a breaker, the breaker will likely catch on flame. Everybody knows that we need an adequately sized circuit breaker that allows for sufficient electric current.
